Sandwich housing for Sun Hydraulics cartridge valves, supplied without valve. Cavity T-2A, stack height 63,2 mm, NG10 x&y. BODY: ISO-05H SANDWICH T-2A CAVITY ON B, PILOT TO A.
BJB is a sandwich housing for Sun Hydraulics cartridge valves, supplied without a cartridge, for a cartridge valve with cavity T-2A. Stack height 63,2 mm, size NG10 x&y. The housing is sold separately – for fitting your own cartridge, replacing a housing in an existing stack or building a function that is not available as a complete manifold.
Sun’s designation on the drawing: BODY: ISO-05H SANDWICH T-2A CAVITY ON B, PILOT TO A.
Versions in the Hydnet range: BJB/M T-2A (part no. 236-1103), BJB/T T-2A (part no. 236-1217). Suffix: /M = aluminium, /T = steel with metric threads. Contact us if you are unsure which version you need.
The same housing is used in the following complete manifolds (housing + valve):
The image shows the housing symbol with ports and cavity. The complete Sun drawing with port layout and dimensions is available as the second image and as a datasheet, and a STEP file for CAD can be downloaded.
| Cavity | T-2A |
|---|---|
| Height of Manifold | 63,2 |
